Product Characteristics
●Simple Process of material,
●Big Feeding Size,
●High Reduction Ratio,
●Low Power Consumption,
●Long Lifetime of Wear Resistance Parts,
●Low investment and Operation Cost.
Product Characteristics
●In order to m for working situation of rainy wet material and much clay mixture，the special discharge structure is applied to eliminate clay sticking
●The specialized facilities such as the carriage and the hammer extracting shaft and grate fetching carts are provided in order to facilitate the replacement of wearing parts
●Provide the full width feeding roller for large scale single rotor crusher is offered to alleviate the impact of rock on the rotors，and make sure the operation of the rotors is more stable.
●Application of special Metal Separator to remove out metal items and ensure safe and reliable operation
●Easy operation and convenient maintenances，lower labor intensity
Single-stage Hammer Crusher Technical Specification
| Model |
Capacity
(t/h) |
Max Feeding Size
(mm) |
Output Size（mm）,
Residue 10% |
Motor Power
（kW） |
| TkPC |
22D25 |
1400~1800 |
1200×1400×1800 |
25~75 |
|
| 20D22 |
1200~1400 |
1200×1200×1500 |
|
| 20D20 |
1100~1300 |
1200×1200×1500 |
|
| 20D18 |
1000~1200 |
1100×1200×1500 |
|
| 18D20 |
900~1100 |
1100×1200×1500 |
|
| 18D18 |
800~1000 |
1000×1200×1500 |
|
| 16D14 |
360~500 |
700×700×1000 |
|
| 14D14 |
250~300 |
600×600×800 |
|
| 14D16 |
300~400 |
600×600×800 |
|
| 14D12 |
200~250 |
600×600×800 |
|
| 20.22 |
550~700 |
1000×1000×1250 |
|
| 20.18 |
350~550 |
800×1000×1250 |
|
| 14.12 |
80~130 |
600×1600×900 |
|
| LPC |
1020D22 |
1200~1400 |
1200×1200×1500 |
|
| 1016D16 |
500~700 |
800×800×1200 |
|
| 1020R22 |
600~1000 |
1100×1100×1500 |
|
| 1020R20 |
500~800 |
|
| 1020.18 |
400~500 |
800×1000×1250 |
|
| 2012.11 |
50~80 |
<500 |
30 |
|
| PC1609 |
50~70 |
600×600×600 |
≤25 |
110 |
| PC1612 |
100~140 |
800×800×800 |
≤25 |
220 |
| PCF2012/11 |
50~70 |
500×500×600 |
≤25 |
90-110 |
| PCF1412 |
80~120 |
600×600×600 |
≤25 |
130-190 |
| PCF1616 |
150~240 |
800×800×800 |
≤25 |
250-350 |
| PCF1618 |
240~280 |
800×800×800 |
≤25 |
355-400 |
| PCF1817 |
280~320 |
800×800×800 |
≤25 |
400-560 |
| PCF1818 |
320~350 |
800×800×1000 |
≤25 |
560-630 |
| PCF2018 |
350~450 |
1000×1000×1000 |
≤25 |
630-710 |
| PCF2022 |
400~600 |
1000×1000×1500 |
≤25 |
710-800 |
| PCF2022 |
600~800 |
1000×1000×1500 |
≤75 |
800-900 |
| PCF(NPC)2025 |
900~1000 |
1000×1000×1500 |
≤75 |
900-1000 |
| 2NPC1018 |
1000~1200 |
1000×1000×1500 |
≤75 |
2×(560-630) |
| 2NPC1820 |
1100~1300 |
1000×1000×1500 |
≤75 |
2×(630-710) |
| 2NPC2020 |
1200~1400 |
1000×1200×1500 |
≤75 |
2×(710-800) |
| 2NPC2022 |
1400~1500 |
1000×1200×1500 |
≤75 |
2×(800-900) |
| 2NPC2025 |
1500~1700 |
1000×1200×1500 |
≤75 |
2×(900-1000) |
| 2NPC2225 |
1800~2100 |
1000×1200×1500 |
≤75 |
2×(1120-1300) |
|
